Unox · XAFR-04FS-ETLV
Unox XAFR-04FS-ETLV Rosella Bakerlux Full Size Countertop Left Handle Convection Oven – 208-240V
Made inItaly- ENERGY STARcertified
- Plug: NEMA 6-50P
- Construction: Stainless steel
- Certification: ENERGY STAR
Questions about this product
What are the dimensions and weight of the Unox XAFR-04FS-ETLV?
The Unox XAFR-04FS-ETLV measures 31.5" (80 cm) wide, 30.5" (77 cm) deep and 19.8" (50 cm) high, and weighs 161 lb (73 kg).
What power supply does the Unox XAFR-04FS-ETLV need?
Plug: NEMA 6-50P; Power supply: Electric; Voltage: 240V 3~ / 208V 3~ / 240V 1~ / 208V 1~; Electric power: 5,9-7,6 kW; Frequency: 60 Hz.
What is the capacity of the Unox XAFR-04FS-ETLV?
Chamber capacity: 3.6 cuFt.
What certifications does the Unox XAFR-04FS-ETLV have?
Energy Star: Yes; cMETus: Yes.
Is the Unox XAFR-04FS-ETLV in stock, and can I buy it online?
It is in stock and can be bought online by card: choose a delivery option at checkout, and taxes and the final total are shown before payment.
How much does shipping cost for the Unox XAFR-04FS-ETLV?
Norpex ships to delivery addresses across Canada. Equipment ships from distributor warehouses, so dispatch timing depends on the supplier and the destination. For items that can be bought online, shipping is calculated at checkout from live carrier rates for the delivery address and confirmed before payment. Some products ship free: their product page says so, and checkout applies it automatically. There is no flat-rate offer.
Can I return the Unox XAFR-04FS-ETLV?
The returns rule depends on the type of item. All sales at Norpex are final: commercial equipment, smallwares, tabletop and supplies cannot be returned or exchanged. Damaged, missing or wrong items are made right when reported on time. Commercial equipment is final sale with no returns or exchanges, so confirm voltage, phase, gas type and door swing before ordering.
What warranty comes with the Unox XAFR-04FS-ETLV?
The manufacturer lists: 1 year parts and labor (glass door not included). Warranty terms are set by each manufacturer and vary by product line.
Is there a spec sheet for the Unox XAFR-04FS-ETLV?
Yes. The manufacturer's spec sheet is under Manuals and documents on this page, as a PDF you can download.
Shipping time
Leaves the warehouse in 1–3 business days
Delivery 7–10 business days after it ships
- Save $5,057.2044% below the maker's list price of $11,463.00
Questions before you buy?
How checkout works
Choose available delivery options and continue to secure payment at checkout. Taxes and the final total are shown before payment.
Pay your way
About these plans
Before tax and delivery. Klarna and Afterpay plans are approved and set at checkout.
From about $557.20/moKlarna monthly financing
12 monthly payments · 7.99%–34.9% APR, set by Klarna at checkout on approval
- LEASEAbout $208.19/mo · $48.04/wk
Delivery discount
30% off delivery or more, and it can be free depending on the order and your postal code.
- Delivery
Shipping and delivery
Read the full shipping pageShipping options are confirmed before you pay.
Shipping is calculated at checkout for supported items and Canadian delivery addresses, and confirmed before you pay.
We prepare your order and hand it to the carrier within 1–3 business days of payment.
Delivery takes 7–10 business days after it ships.
Ranges, refrigeration, furniture and other heavy items ship by freight carrier. Tell us if you need a liftgate, a delivery appointment or inside delivery.
These are estimates: freight bookings, special-order items, remote addresses and carrier delays can add time. If your order runs late, we will email you.
- Returns
Returns
Read the returns policyAll sales at Norpex are final: commercial equipment, smallwares, tabletop and supplies cannot be returned or exchanged. Damaged, missing or wrong items are made right when reported on time, so inspect every delivery before signing for it.
- Payment
Secure payment
Terms of saleCheckout runs on Stripe; card numbers never reach Norpex. A card is authorized at checkout and charged only after we confirm availability with the supplier; if the order cannot be filled, the hold is released.
Klarna and Afterpay plans are approved and set at checkout. Bank transfer and Interac e-Transfer are offered at checkout too.
- Sold by
Norpex
About NorpexNorpex is a business name of 12756528 Canada Inc.. Orders ship from our fulfillment center or the supplier's Canadian warehouse, whichever is closest to you.
- Talk to a person
- (226) 336-9954, Mon–Fri 8am–6pm ET.
Project pricing
Start your project quoteSend your equipment list, drawing or spec sheet and we match each line to live Canadian inventory, then get back to you with pricing, financing and freight within one business day.
Prefer to talk? Call (226) 336-9954.
Product details
Top highlights
- Model
- XAFR-04FS-ETLV
- Brand
- Unox
- Department
- Cooking Equipment
- Plug
NEMA plug
The NEMA code names the shape of the plug and the outlet it fits (for example 5-15P is the standard 15 A, 120 V plug). The outlet at the counter has to match it, or an electrician fits one that does. - NEMA 6-50P
- Construction
- Stainless steel
- Certifications
ENERGY STAR
An efficiency label, administered in Canada by Natural Resources Canada, for equipment that meets set energy-use criteria. Some utilities offer rebates on certified models.- Country of origin
- Italy
About this item
- Stainless steel and a double-glass door construction.
- 4 full-size sheets capacity.
- 2.4″ touch control Panel that stores 99 programs.
- Plus technology with a 2-speed auto-reversing fan.
See moreSee less
- Designed with a left-handle door orientation.
- Plus technology that extracts excess humidity.
- Integrated Wi-Fi and USB ports for rapid recipe uploads.
- LED lighting system in the chamber.
Specifications
General3
- Line
- BAKERLUX SHOP.Pro TOUCH
- Door
- Left-Hinged
- Energy Star
- Yes
Electrical1
- Plug
- NEMA 6-50P
Tray specifications1
- Distance between trays
- 2 in
Certifications1
- cMETus
- Yes
Specifications14
- Shelf clearance
- 3"
- Fans
- 2
- Temperature range
- 0–260°C / 32–500°F
- Chamber dimensions
- 17.4" L x 27.4" W x 13.2" H
- Warranty
- 1 year parts and labor (glass door not included)
- Country of Origin
- Italy
- Type
- Commercial convection ovens with humidity
- Trays
- 4 trays 18"x26"
- Panel
- 2.4" Touch control panel
- Power supply
- Electric
- Tray size
- 18"x26"
- Voltage
- 240V 3~ / 208V 3~ / 240V 1~ / 208V 1~
- Electric power
- 5,9-7,6 kW
- Frequency
- 60 Hz
Construction2
- Door swing
- Top to bottom
- Construction
- Stainless steel housing & cooking chamber, double-pane glass door, insulated baking cavity for thermal efficiency and user safety
Capacity1
- Chamber capacity
- 3.6 cuFt
Dimensions4
- Length
- 30.5" (77 cm)
- Width
- 31.5" (80 cm)
- Height
- 19.8" (50 cm)
- Weight
- 161 lb (73 kg)
Shipping1
- Shipping weight
- 161 lb (73 kg)
Description
- Stainless steel and a double-glass door construction
- 4 full-size sheets capacity
- 2.4″ touch control Panel that stores 99 programs
- AIR. Plus technology with a 2-speed auto-reversing fan
- Includes the STEAM. Plus humidity system
- Designed with a left-handle door orientation
- DRY. Plus technology that extracts excess humidity
- Integrated Wi-Fi and USB ports for rapid recipe uploads
- LED lighting system in the chamber
Description
The Unox XAFR-04FS-ETLV is a convection oven engineered for the needs of professional bakeries and commercial cafes. This Rosella model from the Bakerlux Shop. Pro Touch series is designed specifically for full-size pans, providing a spacious cooking environment while maintaining a compact countertop footprint. Featuring a left-handle configuration, this oven provides ergonomic accessibility for specific kitchen line layouts, ensuring that staff can move efficiently between prep and baking stations.
fitted with a 2.4″ touch control panel, the XAFR-04FS-ETLV allows chefs to store up to 99 programs with 9 cooking steps each, ensuring total consistency across multiple shifts. The unit employs advanced AIR. Plus technology with a 2-speed reversing fan to distribute heat evenly across all 4 shelves. Additionally, the STEAM. Plus system delivers controlled humidity for creating perfectly crusty breads and delicate pastries, making it a versatile asset for any foodservice operation focused on baked goods.
includes a robust stainless steel interior and a high-strength door system built to withstand thousands of openings. The integrated Wi-Fi and USB connectivity allow for easy data transfer and recipe management, helping operators standardize their menu across different locations. The Rosella delivers rapid preheating and recovery times, ensuring that your bakery production never slows down during peak morning rushes.
Read more
This item meets NSF’s standards that focuses on public health protection, ensuring the item is designed and constructed in a way that promotes food safety.
This item meets MET’s minimum requirements of the applicable safety standards and continued compliance to these standards as evidenced by periodic factory follow up inspections.
Manuals and documents4
4 documents
- Unox XAFR-04FS-ETLV User manualOperation and usePDF, opens in a new tab
- Unox XAFR-04FS-ETLV Installation manualInstallationPDF, opens in a new tab
- Unox XAFR-04FS-ETLV Spec sheetSpec sheetPDF, opens in a new tab
- Unox XAFR-04FS-ETLV BrochureBrochurePDF, opens in a new tab
