Prince Castle – Contact Toaster Single Sided – CTS

The Prince Castle CTS is a single-sided contact toaster with a dual-level platen system designed to handle a wide range of thick and thin breads with precision. The adjustable compression avoids bun marking and ensures even caramelization across every bread type — from standard buns and bagels to artisan breads and specialty items.

Variable speed control allows adjustable pass-through times from 9 to 40 seconds across a temperature range of 100°F to 550°F, giving operators full control over toast level for each menu item. The heavy-duty platen retains heat throughout the day, delivering consistent results from open to close.

An LCD screen with simple digital commands enables seamless operation and quick setting adjustments, simplifying staff training and reducing onboarding time. Choose from wire or silicone belt options to match your menu and cleaning preferences.

At 115V with a NEMA 5-15P plug, the CTS runs on a standard outlet — no special electrical required. Stainless steel construction with non-stick release sheets and removable conveyor belts makes cleaning quick and hassle-free. The heat-shield design keeps exterior surfaces cool while enhancing energy efficiency.

Standard Features:

• Single-sided contact toaster with dual-level platen
• Adjustable compression — even caramelization without bun marking
• Variable speed — 9 to 40 second pass-through time
• Temperature range: 100°F–550°F (38°C–288°C)
• Throughput: 1,200 buns per hour
• Two belt options: wire or silicone
• LCD screen with simple digital commands
• Heavy-duty platen retains heat all day
• Standard 115V outlet — no special electrical required
• Non-stick release sheets prevent residue build-up
• Removable conveyor belts for easy cleaning
• Stainless steel construction
• Heat-shield design keeps exterior surfaces cool
• Durable components minimize replacements

Technical Specifications:

• Voltage: 115V, 60 Hz
• Wattage: 1,550W
• Amperage: 15.5A
• Plug: NEMA 5-15P
• Bread Diameter: 5.5" (14 cm)
• Crown Range: 0.5"–1.25"
• Heel Range: 0.3"–1.0"
• Dimensions (W × D × H): 20.3" × 6.5" × 22.2" (51.4 × 16.5 × 56.4 cm)
• Unit Weight: 65 lbs (29.5 kg)
• Shipping Weight: 68 lbs (31 kg)
• Certifications: UL Safety, UL Sanitation, CE, EAC, UKCA
• Warranty: 1-year parts and labour

Available Models (North America):

• CTS-W — Wire belt, 115V, NEMA 5-15P
• CTS-WS — Silicone belt, 115V, NEMA 5-15P

Accessories:

• 511-140 — Butter Wheel
• 299-061S — Release Sheet Kit
• 299-063S — Silicone Belt
