Avancini · 13440 · TRD110
Avancini La Pastaia TRD 110 75 lb/hr Floor Model Pasta Machine with Dual Tank and Cooling System, 208 V, 3 Ph | Trento
- 1-yearmanufacturer warranty
Made inItaly
- Voltage: 208V
- Phase: Three phase
- Plug: NEMA L15-20P
- Certification: CE certified
Questions about this product
What are the dimensions and weight of the Avancini 13440?
The Avancini 13440 measures 22" (56 cm) wide, 41.33" (105 cm) deep and 37.4" (95 cm) high, and weighs 385 lb (174.6 kg).
What power supply does the Avancini 13440 need?
Power: 1.5 + 0.55 kW; Electrical: 208V/60Hz/3; Plug Type: NEMA L15-20P.
What is the capacity of the Avancini 13440?
Max Hourly Production: 75 lb / 34 kg; Dough Capacity: 33 + 33 lb / 15 + 15 kg.
What certifications does the Avancini 13440 have?
Certifications: CE.
Is the Avancini 13440 in stock, and can I buy it online?
It is in stock and can be bought online by card: choose a delivery option at checkout, and taxes and the final total are shown before payment.
How much does shipping cost for the Avancini 13440?
Norpex ships to delivery addresses across Canada. Equipment ships from distributor warehouses, so dispatch timing depends on the supplier and the destination. For items that can be bought online, shipping is calculated at checkout from live carrier rates for the delivery address and confirmed before payment. Some products ship free: their product page says so, and checkout applies it automatically. There is no flat-rate offer.
Can I return the Avancini 13440?
The returns rule depends on the type of item. All sales at Norpex are final: commercial equipment, smallwares, tabletop and supplies cannot be returned or exchanged. Damaged, missing or wrong items are made right when reported on time. Commercial equipment is final sale with no returns or exchanges, so confirm voltage, phase, gas type and door swing before ordering.
What warranty comes with the Avancini 13440?
The manufacturer lists: 1 Year Parts Warranty, 1 Year Labor Warranty. Warranty terms are set by each manufacturer and vary by product line.
Is there a spec sheet for the Avancini 13440?
Yes. The manufacturer's spec sheet is under Manuals and documents on this page, as a PDF you can download.
Can the two tanks run different recipes at the same time?
Yes — the dual 33 + 33 lb / 15 + 15 kg tanks let you prepare two distinct doughs so you can switch extrusion from one recipe to the other without emptying a single tank.
Does the machine need a water connection?
Yes — the cooling system at the back uses a cold water inlet and a drain as an internal loop; a certified plumber should make the connections.
Are extrusion dies included?
No — the cutting assembly comes with the machine but dies for specific pasta shapes are sold separately and must be selected for the profiles you want to produce.
Shipping time
Leaves the warehouse in 1–3 business days
Delivery 7–10 business days after it ships
- Save $16,659.4038% below the maker's list price of $42,716.42
Questions before you buy?
How checkout works
Choose available delivery options and continue to secure payment at checkout. Taxes and the final total are shown before payment.
Pay your way
About these plans
Before tax and delivery. Klarna and Afterpay plans are approved and set at checkout.
- LEASEAbout $846.85/mo · $195.43/wk
Delivery discount
30% off delivery or more, and it can be free depending on the order and your postal code.
- Delivery
Shipping and delivery
Read the full shipping pageShipping options are confirmed before you pay.
Shipping is calculated at checkout for supported items and Canadian delivery addresses, and confirmed before you pay.
We prepare your order and hand it to the carrier within 1–3 business days of payment.
Delivery takes 7–10 business days after it ships.
Ranges, refrigeration, furniture and other heavy items ship by freight carrier. Tell us if you need a liftgate, a delivery appointment or inside delivery.
These are estimates: freight bookings, special-order items, remote addresses and carrier delays can add time. If your order runs late, we will email you.
- Returns
Returns
Read the returns policyAll sales at Norpex are final: commercial equipment, smallwares, tabletop and supplies cannot be returned or exchanged. Damaged, missing or wrong items are made right when reported on time, so inspect every delivery before signing for it.
- Payment
Secure payment
Terms of saleCheckout runs on Stripe; card numbers never reach Norpex. A card is authorized at checkout and charged only after we confirm availability with the supplier; if the order cannot be filled, the hold is released.
Klarna and Afterpay plans are approved and set at checkout. Bank transfer and Interac e-Transfer are offered at checkout too.
- Sold by
Norpex
About NorpexNorpex is a business name of 12756528 Canada Inc.. Orders ship from our fulfillment center or the supplier's Canadian warehouse, whichever is closest to you.
- Talk to a person
- (226) 336-9954, Mon–Fri 8am–6pm ET.
Project pricing
Start your project quoteSend your equipment list, drawing or spec sheet and we match each line to live Canadian inventory, then get back to you with pricing, financing and freight within one business day.
Prefer to talk? Call (226) 336-9954.
Product details
Top highlights
- Model
- 13440
- Brand
- Avancini
- Department
- Food Preparation
- Maker's model
- TRD110
- Voltage
- 208V
- Phase
Phase
Single phase is the ordinary supply most plug-in equipment uses (120 V or 208 to 240 V). Three phase is a heavier commercial supply that large ovens, fryers and dishwashers use; an electrician can confirm which your building has. - Three phase
- Plug
NEMA plug
The NEMA code names the shape of the plug and the outlet it fits (for example 5-15P is the standard 15 A, 120 V plug). The outlet at the counter has to match it, or an electrician fits one that does. - NEMA L15-20P
- Certifications
CE
The maker's declaration that the product meets European safety rules. It is not a Canadian certification, so look for a CSA, cETLus or cULus mark as well.- Manufacturer warranty
- 1 year, parts and labour
- Country of origin
- Italy
About this item
- Continuous floor-model pasta extruder with dual dough tanks for making shaped pasta; suited to operations that need two separate doughs or steady small-batch extrusion at a moderate hourly rate of 75 lb / 34 kg.
- This model is for kitchens that want a compact floor extruder capable of running two separate doughs back-to-back or switching blends without stopping. With dual 33 + 33 lb / 15 + 15 kg tanks it handles small-to-medium batches and short production runs where you need consistent extrusion and frequent changeovers between dough types.
- Check before ordering: Electrical supply: this unit is 208V/60Hz/3 — confirm available circuit and breaker with an electrician. Cooling water: the rear cooling system requires a cold water inlet and a drain; plan for a certified plumber to connect the inlet/outlet loop. Dies and shapes: cutting assembly is included but dies are sold separately — confirm which die profiles are required for desired pasta shapes. Shipping and placement: unit shipping weight is 430 lb (195 kg); verify receiving access and floor capacity for that crate weight.
- Create your own signature pasta with our pasta machine.
See moreSee less
- These pasta extruders are ideal for restaurant and supermarket applications.
- Just simply load all ingredients into the hopper until the dough is extruded through the nozzle producing perfectly shaped pasta at any given time.
- Cooling System – The back of the unit with the cooling system feature is equipped with water supply inlet/outlet.
- Connect the inlet with COLD water connection.
Specifications
Specifications6
- Specification
- Details
- Max Hourly Production
- 75 lb / 34 kg
- Dough Capacity
- 33 + 33 lb / 15 + 15 kg
- Power
- 1.5 + 0.55 kW
- Electrical
- 208V/60Hz/3
- Cooling System
- Yes (water cooling for continuous operation)
Details3
- Country of Origin
- Italy
- Certifications
- CE
- Warranty
- 1 Year Parts Warranty, 1 Year Labor Warranty
Electrical1
- Plug Type
- NEMA L15-20P
Dimensions4
- Weight
- 385 lb (174.6 kg)
- Length
- 41.33" (105 cm)
- Width
- 22" (56 cm)
- Height
- 37.4" (95 cm)
Shipping4
- Box length
- 37" (94 cm)
- Box width
- 28" (71 cm)
- Box height
- 44" (112 cm)
- Shipping weight
- 430 lb (195 kg)
Description
Create your own signature pasta with our pasta machine. These pasta extruders are ideal for restaurant and supermarket applications. Just simply load all ingredients into the hopper until the dough is extruded through the nozzle producing perfectly shaped pasta at any given time.
Important:
Cooling System – The back of the unit with the cooling system feature is equipped with water supply inlet/outlet. Connect the inlet withCOLDwater connection. Please note that one side to be used as input and other as a drain (Certified Plumber is required). The inlet/outlets are identical, and it does not matter what is used as the supply or drain, as the internal supply is just a loop for the head and die to be kept cold.
Cutting assembly included. Dies are sold separately.
