The Tunnel 50 Heating System is specifically designed for the food and pharmaceutical industries, providing maximum efficacy and versatility with a wide range of shrink films. This robust and efficient heating system ensures high-quality packaging results for various applications. The Minipack Tunnel 50 Heating System is the ideal solution for those in the food and pharmaceutical industries looking for a reliable, efficient, and versatile packaging system. Its advanced features and durable construction ensure it meets the high demands of industrial packaging applications.
Key Features:
Heating Area:
- Tunnel Inlet: 16″ x 9″ H
- Tunnel Length: 28″
- Shrink Film Types: All
Performance:
- Tunnel Heater Wattage: 7KW
- Power Supply: 208V / 3ph / 21A
Display & Controls:
- Water Resistant LED Display
- Digital Display
- Customizable Programs: 9
Operational Features:
- Programmable Conveyor Speed
- Adjustable Air Flow
- Automatic Cool-Down
- Adjustable Conveyor Height
- Self-Rotating Conveyor Rolls
- Double-Insulated Walls
- Exit Roll Conveyor: 18”
Service:
- Easy Frontal Access
- Indicating Display
- Error Codes
- 1 Year Limited Warranty
Housing & Dimensions:
- Material: Steel / Baked Enamel
- Machine Size (W x L x H): 50.39″ x 33.46″ x 57.87″
- Working Height: 34″
- Locking Casters
- Shipping Weight: 520lbs
